Higher Test Marks with Free Online ACP-01101 Exam Practice

Assess the CertsIQ’s updated ACP-01101 exam questions for free online practice of your Autodesk Certified Professional in AutoCAD for Design and Drafting test. Our ACP 01101 dumps questions will enhance your chances of passing the Autodesk Certified Professional certification exam with higher marks.

Question 1

You are modifying an AutoCAD drawing for a customer.

You would like to bring your customers attention to a specific area of the drawing that you modified for

review.

Which type of object is conventionally used?

Options :

A : A viewport

B : A construction line

C : A solid hatch

D : A revision cloud

Answer: D

Question 2

Refer to the exhibit.

This section view was dimensioned using Baseline Dimensions The dimensions are too close together which

impacts the drawing's legibility. What is the most efficient method to avoid this problem in the future?

Options :

A : Copy and Paste

B : Move

C : Dimension Style Manager

D : Grip Edit

Answer: C

Question 3

Your company asks you to research alternative editable CAD formats to export to for non-AutoCAD users.

Which three alternative CAD file formats can be exported from AutoCAD? (Select 3)

Options :

A : RVT

B : STL

C : IAM

D : BMP

E : DWF

Answer: A,B,C

Question 4

Exhibit

The viewport scales in the title block shown are field value as extracted from the properties of each viewport.

When using the Insert Field command to edit the text value and generate the viewport scale, which object

property should you use, if the default scale list is being used?

Options :

A : Standard scale

B : Visual style

C : Display locked

D : Object name

Answer: A
